Cycles forages & fibrous materials
Control feed placement with less spillage or over-filling
Benefits
- • Ingredients are returned to the box and completely blended before unloading
- • Mixes additives evenly throughout the load
- • All chains and stub recycle auger run in unison for optimum capacity
- • Mixing time - 4 to 5 minutes
- • Trouble-free chain and flight action
- • All-steel welded construction
- • Low profile for easy loading
- • Low power for easy mixing
- • Easy control of feed placement with less spillage or over-filling
| Box Size | 4' x 10' | 4' x 12' | 5' x 12' | 5' x 14' |
|---|---|---|---|---|
| Weight | 1,800 lb. | 2,160 lb. | 2,680 lb. | 3,900 lb. |
| Overall Length | 182" | 206" | 213" | 240" |
| Overall Width | 80" | 80" | 92" | 92" |
| Discharge Height | 48" | 48" | 48" | 50" |
| Leaf Springs | Optional | Optional | Optional | Standard |
| Capacity | 115 Bu. | 140 Bu. | 190 Bu. | 250 Bu. |
Standard Features
- • High visibility front discharge with overhang spout
- • Strong apron chain (pintle on 5' widths) where a slow, steady drag is required
- • Lift chain is high-speed roller for smooth action and long life
- • High-strength axles, spindles and hubs
- • Oil bath gearbox
- • Shear pin PTO
Optional Features
- • Bunk rail
- • Flotation tires
- • Scoop rack
- • Electronic scales
- • Cross conveyor extension
- • Fenders
- • Plastic floor
- • Stage coach rear end
